Anti Glare Cover Glass for Displays & Touchscreens
Anti Glare Cover Glass for Clearer Displays in Bright Environments
Our anti glare cover glass is designed to reduce distracting reflections and improve display readability in bright indoor and outdoor environments. We manufacture custom AG glass for LCD, OLED, touchscreen, HMI, industrial control panels, automotive displays, kiosks and other electronic devices.
Available in custom thicknesses, dimensions, shapes and surface finishes, our anti glare cover glass can be combined with chemical strengthening, CNC machining, silk screen printing, AR or AF treatment according to your application requirements. AG performance can also be customized by haze, gloss, surface roughness and optical transmittance.
Whether you need prototype samples or production quantities, we can manufacture anti glare cover glass according to your drawings and technical specifications.
What Is Anti Glare Cover Glass?
Did you ever tried using your phone in bright sunlight? Or struggled with reflections on a store display? That’s why anti-glare glass comes in. We’ve engineered our anti glare cover glass to solve these real-world problems that frustrate users daily. Unlike standard glass that acts like a mirror in bright conditions, our AG treatment makes displays readable anywhere – from sunny outdoor cafes to brightly lit retail stores.
How Anti Glare Cover Glass Reduces Reflections
Let’s look at below table:
| Feature | Our AG Glass | Standard Glass |
|---|---|---|
| Glare Reduction | Up to 85% | 0% |
| Surface Roughness | 0.1-0.3μm | <0.01μm |
| Light Diffusion | 5°-15° | 0° |
| Fingerprint Visibility | 50% less noticeable | Highly visible |
| Cleaning Frequency | Every 2-3 days | Multiple times daily |
Cover Glass Specifications
| Parameter | Custom Specification |
|---|---|
| Glass Material | Soda-Lime / Aluminosilicate |
| Thickness | 0.5–3.0 mm or Custom |
| AG Treatment | Chemical Etching / Custom |
| Haze | Custom |
| Gloss | Custom |
| Light Transmittance | Custom |
| Surface Roughness | Custom |
| Size | Custom |
| Shape | Custom |
| Edge Processing | CNC / Polished |
| Strengthening | Chemical / Thermal |
| Printing | Silk Screen |
| AR Treatment | Optional |
| AF Treatment | Optional |
Cover Glass Surface Options
1. AG + AR
For applications requiring both glare reduction and reduced surface reflection.
2. AG + AF
For touchscreen applications requiring glare reduction together with easier cleaning and fingerprint resistance.
3. Only AG Treatment
For applications that primarily require glare reduction and improved readability.
Applications of Anti Glare Cover Glass
Industrial HMI Displays
Outdoor Digital Displays
Automotive Displays
Retail & POS Displays
Consumer Electronics
Medical Displays
Custom Anti Glare Cover Glass Manufacturing
We manufacture the cover glass according to customer drawings, dimensions and optical requirements. Custom processing includes glass cutting, CNC machining, edge polishing, hole drilling, chemical strengthening, thermal tempering, silk screen printing and AG surface treatment.
- Custom thickness
- Custom size
- Custom shape
- CNC holes and cut-outs
- Edge processing
- Chemical strengthening
- Thermal tempering
- Silk screen printing
- AG treatment
- AG + AR
- AG + AF
Frequently Asked Questions
What is anti glare cover glass?
Cover glass is display glass treated with a controlled surface texture that diffuses reflected light and reduces distracting glare. It is commonly used for touchscreens, HMI panels, outdoor displays and other electronic displays.
What is the difference between AG and AR glass?
AG glass diffuses reflected light to reduce visible glare, while AR glass uses an optical coating to reduce surface reflectance and increase light transmission. AG and AR treatments can also be combined for specific display requirements.
Can anti glare cover glass be chemically strengthened?
Yes. Anti glare cover glass can be chemically strengthened to improve surface strength and resistance to mechanical damage, depending on the glass material and thickness.
Can you customize the haze level of AG glass?
Yes. Haze, gloss, surface roughness and light transmittance can be customized according to the display’s optical and environmental requirements.
Can AG cover glass be used for touchscreens?
Yes. AG cover glass can be manufactured for capacitive and other touchscreen applications. The AG surface characteristics can be selected to balance glare reduction, image clarity and touch.
