AG AR AF Coated Cover Glass | Custom OEM Manufacturer

WM Cover Glass provides custom AG AR AF coated cover glass solutions for touchscreen displays, industrial equipment, automotive displays and electronic devices. As an OEM cover glass manufacturer, we offer anti-glare (AG), anti-reflective (AR) and anti-fingerprint (AF) surface treatments to improve display visibility, optical performance and user experience.

Our coated cover glass can be customized with different glass materials, thicknesses, dimensions, CNC machining, silk screen printing and chemical strengthening according to customer requirements.

AG AR AF Coated Cover Glass for Outdoor Display: Excellent Screen Performance

In Weiman, we offer various of cover glass customization options especially for AG AR AF coated cover glass for outdoor display. It’s because with more than 10 years experience we deeply understand different customer’s actual applications, so we fabricate the cover glass in consider of durability, cost efficiency, optical performance and surface quality to make our customer believe it worth to investigate.

AG AR AF Coated Cover Glass Specifications

What Should be Considered For AG AR AF Coated Cover Glass for Outdoor Display Applications?

For cover glass in outdoor screen application, sunlight, touch and clarity will be important issues to be mentioned. So usually 3 kinds of coatings(AG, AF, AR) to be added.

AG(Anti Glare): You can imaging when screen in outdoor with sunlight directly to the screen and reflect to the eye. The treatment can scatter the light into different direction, which can protect the eye and viewable.

AF(Anti Fingerprint):There are usually 2 simple solutions with the coating:

1.It can protect the AR layer from easy removed.

2.Since it take lotus principle, it can make the glass to be cleaned easily.

AR(Anti reflection): It can greatly improve light transmittance(To glass itself, the light transmittance is 91%+), with single side it can increase 3-4% and double sides up to 99%.

A simple picture to tell you these 3 kinds of coatings:

Meanwhile, chemically strengthened will be needed to add on AG AR AF coated cover glass which can greatly improve the impact resistance and shock resistance especially for outdoor applications.

What’s The Applications Of Our AG AR AF Coated Cover glass?

Except outdoor application like kiosk, vending machine etc, they also widely applied in car console display screen, consumer electronics and household appliances with premium requirements.

With different application, coatings and printings also exist differences:

For indoor application, AG treatment isn’t used frequently but sometimes in E-book or premium appearance purpose because of its texture.

The AR coatings often used in outdoor machine or car console screen in purpose to improve the viewable experience.

How Weiman Can Guarantee The AG AR AF Coated Cover Glass Quality?

Since raw materials(glass substrate, inks) inspection, to in production inspection and post production inspection, every process we will arrange strict quality control especially finished product to make sure every unit you receive on hand in perfectly good quality including:

Visual Inspection, it’s the most important step to ensure every unit of cover glass surface quality in good condition.

Strengthening test to make sure the hardness can meet expectation with pencil test, CS and DOL tests.

To the silk screen print, we will test its adhesive ability(Paint adhesion test) and use colorimeter to see if the color under control.

Coatings: Different coating has its own way to to test(AR for adhesion, transmittance in different spectral band, AG for VLT, haze and roughness, AF for water angle and rubber tests).

What’s The Packaging For the AG AR AF Coated Cover Glass?

For more than 10 years experience, we deeply under the clean and transportation safety to ensure each unit on your hand is perfect and clean.

First, we will use PE foils for double sides lamination.

Second, every 10pcs will be put into plastic bag for vacuum sealing.

Third, the bag of cover glass will be packed into the carton.

Forth, all cartons will be packed into plywood crating with foam protection.

Why Choose WM Cover Glass for AG AR AF Coating?

Customized coating solutions

Different glass substrate options

Optical performance control

CNC and printing integration

OEM mass production capability

Quality inspection before shipment

Frequently Asked Questions For AG AR AF Coated Cover Glass

What is the difference between AG, AR and AF coating?

AG reduces glare, AR reduces reflection and improves light transmission, while AF reduces fingerprints and improves surface cleanability.

Can AG AR AF coatings be combined on one cover glass?

Yes. AG, AR and AF coatings can be combined according to application requirements, optical performance and surface protection needs.

Can you provide custom AG AR AF coated cover glass?

Yes. We manufacture customized coated cover glass according to drawings, dimensions, thickness and application requirements.

What glass materials can be used for coated cover glass?

Soda lime glass, aluminosilicate glass and chemically strengthened glass can be considered depending on durability and optical requirements.

Request a Quote for AG AR AF Coated Cover Glass

Looking for customized AG, AR or AF coated cover glass for your display project?

Please provide:

• Glass material and thickness
• Glass dimensions or drawings
• Required coating type (AG / AR / AF)
• Optical requirements
• Printing requirements
• Application environment
• Estimated quantity

Our engineering team will review your requirements and provide a suitable coated cover glass solution.
